Reefs RC 1100 Smart Brushless Servo

SPECIFICATIONS: High Torque High Speed Brushless SERVO or WINCH Comes as SERVO out of the Box, can be changed to WINCH with the REEFS LINK (Sold seperately) and Software. BUILT IN PREPROGRAMMED WINCH CONTROLLER SUBMARINE WATERPROOF: 7 Point Seals w/ GRAY HEAT SINK Magnetic Angle Sensor Pulse Width Modulation Control 4 Pole Brushless Motor Voltage: 4.8V - 8.4V Internal: Steel Gears / All CNC Aluminum Casing Bearing Type: 4 Ball Bearings / Weight: 2.99oz Dimension: 1.57 x .79 x 1.5 (LWH) Torque: 760oz @ 6v/ 930oz @7.4v/ 1100oz @8.4v Speed: .16sec @6v/.13sec @7.4v/.12sec @8.4v Spline: 25T Dead Band Width: 2¦Ìs BEC Not Req. (Recommended for max performance) Unload Current: 460mA @ 4.8V / 500mA @ 6.0V / 540mA @ 7.4V / 580mA @ 8.4V Load Current: 5400mA @ 4.8V / 6000mA @ 6.0V / 6800mA @ 7.4V / 7500mA @ 8.4V For programming, the USB Link is required.
